HX-401

        Check Broken Needles: women’s wear, men’s wear, student uniforms, overalls, baby products, knitwear, underwear, socks, fabrics, non-woven fabrics, embroidery, towels, bath towels, carpets, gloves, toys, handicrafts, etc. .

        Through the Inspection Needle: hardware button, metal zipper, Japanese word buckle, bead chain, brooch and other clothing handbags metal accessories over the needle machine.



        1. High Sensitivity, detection gantry height of 12cm, detection of 1.0mm diameter fine iron filings, nine point test method does not miss detection.

        2. All steel frame is beautifully painted body, the whole machine is strong, and it is more beautiful, anti-impact and anti-weak magnetic resonance than traditional aluminum sheet wings; suitable for docking assembly line operation.

        3. super anti-interference computer chip integrated circuit, dual-channel sensor, equivalent to the traditional double-probe needle detector;

        4. All function keys are light touch type membrane switches, which avoids the shortcomings of mechanical buttons being easily damaged;

        5. There is a position display function, and the eight-point part shows the exact broken needle position function;

        6. with a counting function, distinguish between good and bad products (qualified, total, detected);

        7. The alarm function is three kinds of sound, light and stop machine. The sensitivity is adjusted from 1 to 10 levels;

        8. special protection circuit, no object to pass through the automatic shutdown for 10 minutes;

        9. All function settings are completed after the main power is turned on, without starting the motor;

        10. with B / C (accessory / finished product) mode switching function, to adapt to the needle inspection of different products;

        11. When the broken needle or iron object is detected, the sound and light alarm modes are stopped, and the machine returns to the starting point and automatically runs again.
